Cloud Drops - Building an Event-Driven workflow with Event Grid
Event-driven architectures decouple producers from consumers, making them a natural fit for serverless consumption models where you pay only when work is being done. This Cloud Drop builds a real image-processing workflow step by step:
- Source storage account — a Blob Storage container called
imageswhere uploads trigger events. - Queue storage account — a Storage Queue (
work-in-progress) that acts as a durable buffer guaranteeing at-least-once processing. - Event Grid system topic + subscription — created on the source storage account, filtered by subject (
/blobServices/default/containers/images) so only image-container blob-created events are forwarded; the event handler is set to the Storage Queue. - System-managed identity + RBAC — the Event Grid system topic’s managed identity is assigned the Storage Queue Data Message Sender role on the queue storage account, eliminating stored credentials.
- Azure Function queue trigger — consumes and removes messages from the queue, with Application Insights showing execution logs.
The demo also verifies subject filtering by uploading to the thumbnails container and confirming no extra messages appear in the queue, and discusses dead-lettering, retry policies, and the important distinctions between Azure Storage Queues and Azure Service Bus Queues for message-processing guarantees.
